Extraneous Water Sealing System for street manholes (inspection shafts) protects against surface water entering through the ventilation openings of the manhole cover.The Extraneous Water Sealing System is proven to be effective especially with these advantages: It has an aeration and deaeration function, is low-maintenance and convenient due to automatic closing and opening. All materials used are suitable for permanent use in sewer systems.Application areas of the Extraneous Water Sealing SystemSuitable for manhole openings with a diameter of 625 mm +- 5 mmApplicable for overflow heights up to 0.5 m above street levelDesigned for manholes according to DIN 4034 and manhole covers according to DIN 19584 (standard BeGu frame), special mounting supports available on requestAdvantages of the Extraneous Water Sealing SystemReliable sealing of manholes in case of surface water inflowFull aeration according to DIN EN 124 after surface water inflow ceases
Low maintenance due to large sediment collection space
Suitable for overflow heights up to 0.5 m
Special dimensions available on request
Prevention of biogenic corrosion in sewer systems with aeration and deaeration function
Eliminate odor from manholes and protect your manhole structures from corrosion with our odor control system FVA-4 DN1000.
As an alternative to conventional filters deployed at the top of the manhole, this system is installed above the berm. Gaseous pollutants from the sewer system such as hydrogen sulfide (H2S) are therefore retained, preventing odor and sulfuric acid corrosion above the installation level.
Application areas of FVA-4Designed for municipal and industrial wastewater systemsSuitable for manholes with an inner diameter of 1000 mm +- 5 mm and an entrance opening of min. 600 mmThe minimum depth of manhole shafts should be 1.2 mOur odor control systems are designed for manholes according to DIN 4034 and manhole covers according to DIN 19584 (standard BeGu frame), special mounting supports available on request
Get rid of odor complaints from citizens with the Uni-AdSorber! Satisfied sewer system operators choose our Uni-AdSorber DN625 manhole odor cushioning system to efficiently eliminate malodors from sewer shafts. As an alternative to conventional biofilters or activated carbon filters, the Odor Cushioning Systems from UNITECHNICS do not require replacement of the filter material. The filter material rinses itself through rainwater flowing into the shafts or condensed water vapor in the filter. Thus, the filter material is only decomposed by UV light and does not need to be changed. For an additional decomposition of odorous substances, microorganisms are settled in the filter material, which activate the essential biochemical processes.Our manhole odor filter is designed for application in municipal and industrial wastewater systems. Manholes according to DIN 4034 and manhole covers according to DIN 19584 (standard BeGu-frame), special mounting supports available on request.Basic variant - for medium H2S-loads.HD variant - for extreme H2S-loads. HD stands for Heavy Duty - the high-performance version.Please note: special dimensions and special applications (e.g. for aggressive media in industry) are available on request.We have the matching odor filter for every challenge!Application areas of the UNITECHNICS manhole filterManhole filters for municipal and industrial wastewater systems.Our manhole filters are designed for manholes according to DIN 4034 and manhole covers according to DIN 19584 (standard BeGu frame), special mounting supports available on request.The Uni-AdSorber-B (B for Basic, the basic model) manhole filter is designed for predominantly medium H2S loads.The Uni-AdSorber-HD (HD for Heavy Duty, the high performance version) manhole filter for extreme H2S loads.
Advantages of the UNITECHNICS Uni-AdSorberReduction/avoidance of odor by self-regenerating filter material (no replacement of filter material necessary)Additional degradation of odorous substances through settlement of microorganisms in the filter materialSimple installation and dismantlingDirt collector included in the scope of deliveryLow maintenance, cleaned with water onlyWater-permeable during the daySpecial dimensions and special applications (e.g. for aggressive media in industry) are available on requestNo H2S odors from the sewer anymoreAlternative to conventional biofilters or activated carbon filtersThe Uni-AdSorber DN625 is a field-proven manhole filter for municipal and industrial wastewater systems from UNITECHNICS
Having complaints about odor in the sewer? We have the effective solution for you: Odor Sealing System GVS-450-150 for effective prevention of odors from street drains. Fast installation and dismantling is possible with the comfortable handle. The odor sealing flap ensures unobstructed rainwater runoff. Installation position is below the dirt collector. As no consumable material is required, maintenance costs are minimal and no other subsequent costs are incurred.Application areas of GVS-450-150Designed for permanent use in both municipal and industrial wastewater systemsSuitable for street drains according to DIN 4052 (diameter 450 mm)Special dimensions are available on request
With the UNITECHNICS Rat Ball 2.0, we offer a modern and efficient method for combating rats and pests in surface and sewer systems. Developed in close collaboration with pest control experts and sewer network operators, the Rattenkugel stands out for its ease of use and high effectiveness.
Advantages of the UNITECHNICS Rat Ball 2.0:
• Tested according to German Infection Protection Act (IfSG) § 18 (A legally compliant and certified system for pest control.)
• Efficient Bait Placement: The 360° feeding access allows for optimal bait distribution, ensuring maximum efficiency.
• Waterproof: Thanks to the diving bell principle, the bait remains dry even during backflow.
• Flexible Installation: Easy and damage-free installation without manhole entry – ideal for manholes with a diameter of 300 mm and above.
• Sustainable Solution: Durable materials like PE-LD and acrylic glass ensure long-lasting performance and reusability.
• Compatible with all common poison baits: The Rat Ball 2.0 is easily adaptable for use with various types of bait.Product Details:
The compact Rat Ball 2.0 is about the size of a soccer ball and allows for easy installation with a stainless steel rope and weight attached to the debris catcher, without requiring structural modifications to the manhole. The bait is visible through the transparent top shell, eliminating the need for manhole entry. An upgrade kit for older versions is also available.
Field-Proven Efficiency:
The Rat Ball 2.0 has proven highly effective in simulations. Even after 24 hours of backflow, the bait remained untouched by water, underscoring the reliability and durability of this pest control solution.
Why Choose the UNITECHNICS Rat Ball 2.0?
The Rat Ball 2.0 offers a certified and reliable system for rat control that is easy to install, flexible to use, and highly durable. By choosing this advanced technology, you ensure sustainable and efficient protection for your facilities.
